Maverick Series

  • Maximum capacity:Up to 30 m3/hr
  • Maximum pressure:Up to 26 m TDH
  • Designed for solid concentration:Up to 5%
  • Victaulic discharge connections:From 2” up to 3”
  • Rating:0.5 HP up to 3 HP
  • Options:Level sensor or floats

Applications

Removal of water or slurry out of trenches, underground pits and manholes.

3 hp and under pumps Specifications

Pump models Pump performance Pump dimensions
Motor Output Total head Capacity Pump diameter Height Weight Victaulic discharge diameter
[hp - (kW)] [ft - (m)] [Usgpm - (m3/h)] [Inch - (mm)] [Inch - (mm)] [Lbs - (kg)] [Inch - (mm)]
MAV-2.5 0.5 (0.4) 39 (12) 62 (14) 7 (185) 13 (328) 24 (11) 2 (50)
MAV-2.67 0.67 (0.5) 39 (12) 62 (14) 7.5 (188) 12 (304) 21 (9.5) 2 (50)
MAV-21S 1 (0.8) 33 (10) 53 (12) 7.6 (194) 17 (430) 34 (15.5) 2 (50)
MAV-21W 1 (0.8) 59 (18) 82 (19) 7.5 (188) 13 (328) 29 (13) 2 (50)
MAV-22 2 (1.5) 69 (21) 108 (25) 9 (240) 23 (593) 71 (33) 2 (50)
MAV-23A 3 (2.2) 85 (26) 132 (30) 9 (240) 22 (560) 64 (29) 2 (50)
